| Length (Tractor Only with Tracks) |
163 "
(414 cm) |
| Width (basic tractor, tracks) |
72.5 "
(184.2 cm) |
| Height (basic tractor, tracks) |
85.5 "
(217.2 cm) |
| Tractor Weight with Attachment Range |
13,880 lbs |
| Approach Angle |
35.5 deg |
| Ground Clearance |
14.8 "
(37.5 cm) |
| Make and Model |
Perkins 854E-E34TA Tier 4i (Stage IIIB) |
| Rated horsepower |
111 hp
(82.8 kw) |
| Rated Engine RPM |
2200 |
| Number of Cylinders |
4 |
| Max engine operating angle |
30 deg |
| Cooling Medium |
Liquid |
| Fan-type |
Reversable |
| Air Cleaner |
Dual Element With Pre-cleaner |
| Exhaust-type |
DOC/DPF |
| Electrical System |
12 |
| Battery capacity |
950 |
| Alternator-Type |
Brushed, 120A |
| Fuel Tank Capacity |
30 gal
(113.6 L) |
| Sound Power |
108.0 dB(A) |
| Sound Level (In Cab) at Operator's Ear |
87.6 |
| Make and Model |
Rubber with all purpose tread |
| Track Pad Type |
Embedded co-polymer cords |
| Track pad width |
20 "
(50.8 cm) |
| Ground pressure |
4.9 psi
(.3 bar) |
| Max ground speed - high |
10 mph
(16.1 km/h) |
| Max ground speed - low |
6 mph
(9.7 km/h) |
| Park Brake |
Yes |
| Egress points |
2 - Front Door, Rear Window |
| Window Type |
Front - abrasion resistant polycarbonate |
| Window thickness |
.5 "
(1.3 cm) |
| Control System |
Dual joystick |
| Air Conditioner/Heater |
18,500 BTU/33,000 BTU |
| Air Suspension Seat |
Adjustable Suspension w/2" Wide Seat Belt |
| Audio system |
AM/FM/WX |
| Display |
Monocrome |
| Pressurized/Filtered Air |
Std |
| Rollover protective structure (ROPS) verified |
Meets ISO 8082-1:2009 |
| Falling object protective structure (FOPS) verified |
Meets ISO 8083:2006 Level 2 |
| Operator protective structure (OPS) verified |
Meets ISO 8084;2003 |
| Backup camera |
Color, infrared, standard |
| Number of work lights |
4 |
| Work light-type |
Bulb |
| Oil Tank Capacity |
22 gal
(83.3 L) |
| Attachment pump displacement |
85cc |
| Attachment pump flow at max rpm |
45 gpm
(170.3 L/min) |
| Model Name |
FH100 |
| Overall attachment width |
73 "
(185.4 cm) |
| Weight with attachment range |
2650 lbs
(1202 kg) |
| Rotor-type |
Ringed |
| Tip Diameter |
18 "
(45.7 cm) |
| Working Width |
63 "
(160 cm) |
| Quantity of cutting teeth |
12 |
| Rotor rpm |
2130 rpm |
| Rotor drive |
Cogged belt |
| Number of motors |
1 |
| Tip option 1 |
Sharp planar |
| Tip option 2 |
Clad-faced planar |
| Tip option 3 |
Impact-resistant hammer |
