| Length (Tractor Only with Tracks) |
267 "
(678.2 cm) |
| Width (basic tractor, tracks) |
98 "
(248.9 cm) |
| Height (basic tractor, tracks) |
116.7 "
(296.4 cm) |
| Tractor Weight with Attachment Range |
30,100/36,700 lbs |
| Approach Angle |
35 deg |
| Ground Clearance |
14.5 "
(36.8 cm) |
| Make and Model |
Cummins QSL9 Tier 4 Final (Stage IV) |
| Rated horsepower |
300 hp
(223.7 kw) |
| Rated Engine RPM |
2200 |
| Number of Cylinders |
6 |
| Max engine operating angle |
45 deg |
| Cooling Medium |
Liquid |
| Fan-type |
Reversable |
| Exhaust-type |
DOC/DRT/SCR |
| Electrical System |
24 |
| Battery capacity |
1155 |
| Alternator-Type |
Brushless |
| Fuel Tank Capacity |
137 gal
(518.6 L) |
| Rated horsepower |
290 hp
(216.3 kw) |
| Number of Cylinders |
6 |
| Air Cleaner |
Dry Type with pre-cleaner. Primary and secondary elements and restriction indicator |
| Exhaust-type |
Muffler |
| Battery capacity |
1155 |
| Alternator-Type |
Brushless |
| Fuel Tank Capacity |
137 gal
(518.6 L) |
| Make and Model |
Track Industries - Low Ground Pressure |
| Track Pad Type |
5 Ply strips with cross bars |
| Track pad width |
33.3 "
(84.5 cm) |
| Ground pressure |
3.6 psi
(.2 bar) |
| Max ground speed - high |
6 mph
(9.7 km/h) |
| Max ground speed - low |
3 mph
(4.8 km/h) |
| Park Brake |
Yes |
| Make and Model |
Berco - D4 |
| Track Pad Type |
Single Grouser |
| Track pad width |
30 "
(76.2 cm) |
| Ground pressure |
4.7 psi
(.3 bar) |
| Max ground speed - high |
6 mph
(9.7 km/h) |
| Max ground speed - low |
3 mph
(4.8 km/h) |
| Park Brake |
Yes |
| Egress points |
3 - Left and Right Door, Roof Hatch |
| Window Type |
Abrasion Resistant Polycarbonate |
| Window thickness |
.5 "
(1.3 cm) |
| Control System |
Dual Joystick |
| Air Conditioner/Heater |
40,000 BTU/50,000 BTU |
| Air Suspension Seat |
Std |
| Audio system |
AM/FM/NOAA Weatherband/Sirius Ready |
| Display |
7" Color |
| Pressurized/Filtered Air |
Std |
| Rollover protective structure (ROPS) verified |
Meets ISO 8082 |
| Falling object protective structure (FOPS) verified |
Meets ISO 8083 Level 2 |
| Operator protective structure (OPS) verified |
Meets ISO 8084 |
| Backup camera |
Color, Infrared, Standard |
| Number of work lights |
11 |
| Work light-type |
LED |
| Oil Tank Capacity |
57 gal
(215.8 L) |
| Attachment pump-type |
Sauer-Danfoss Series 90 |
| Attachment pump displacement |
250 |
| Attachment pump flow at max rpm |
145 gpm
(548.9 L/min) |
| Auxiliary functions pump displacement |
45 cu-in
(737.4 cu-cm) |
| Model Name |
FH300 |
| Overall attachment width |
100 "
(254 cm) |
| Weight with attachment range |
4800 lbs
(2177.2 kg) |
| Rotor-type |
Ringed |
| Tip Diameter |
25.6 "
(65 cm) |
| Working Width |
82.5 "
(209.6 cm) |
| Quantity of cutting teeth |
23 |
| Rotor rpm |
1790 rpm |
| Rotor drive |
Direct |
| Number of motors |
.2 |
| Hydraulic motor displacement |
160 cu-in
(2621.9 cu-cm) |
| Tip option 1 |
Sharp Planar |
| Tip option 2 |
Clad Faced Planar |
| Tip option 3 |
Impact Resistant Hammer |
| Engine air shutoff |
Electric Actuated |
| Arctic package (diesel fired fluid heater) |
Engine Coolant and Hydraulic Oil |
| Rear mounted winch |
30000 lbs
(13607.8 kg) |
