| Approach Angle |
15 deg |
| Height Range |
146 (370.8 cm) |
| Length with 50" (127 cm) End Idler and 8 ft (2.44 m) Boom |
43 '
(13.1 m) |
| Length with 50" (127 cm) End Idler and 10 ft (3.05 m) Boom |
45.5 '
(13.9 m) |
| Length with 50" (127 cm) End Idler and 12 ft (3.66 m) Boom |
48 '
(14.6 m) |
| Length with 50" (127 cm) End Idler and 14 ft (4.27 m) Boom (with Restraint Bar) |
48.8 '
(14.9 m) |
| Length with 50" (127 cm) End Idler and 16 ft (4.88 m) Boom (with Restraint Bar) |
51.3 '
(15.6 m) |
| Length with 50" (127 cm) End Idler and 18 ft (5.49 m) Boom (with Restraint Bar) |
53.8 '
(16.4 m) |
| Weight Range |
150,000 lb - 205,000 lb (68,039.9 kg - 92,986.4 kg) |
| Width Ranges |
134" (340.4 cm) |
| Make and Model |
Caterpillar C18 ACERT Tier 3 |
| Gross Horsepower |
600 hp
(447.4 kw) |
| Rated Engine RPM |
2100 |
| Number of Cylinders |
6 |
| Fuel Tank Capacity |
370 gal
(1400.6 L) |
| Operating Range |
11.6 hours |
| Fuel Consumption at Full Load |
31.8 gph
(120.4 lph) |
| Maximum Engine Operating Angle (Operating angles do not indicate safe machine operating angles) |
35 deg |
| Air Cleaner |
Dry-type with precleaner |
| Aspiration |
Turbocharged and air-to-air aftercooled |
| Cooling Medium |
Liquid |
| Electrical System |
24 Volt DC |
| Oil Filter |
Full flow |
| Make and Model |
Caterpillar C18 ACERT Tier 4 Final |
| Gross Horsepower |
600 hp
(447.4 kw) |
| Rated Engine RPM |
2000 |
| Number of Cylinders |
6 |
| Fuel Tank Capacity |
370 gal
(1400.6 L) |
| Operating Range |
12.1 |
| Fuel Consumption at Full Load |
30.5 gph
(115.5 lph) |
| Maximum Engine Operating Angle (Operating angles do not indicate safe machine operating angles) |
35 deg |
| Air Cleaner |
Dry-type with precleaner |
| Aspiration |
Turbocharged and air-to-air aftercooled |
| Cooling Medium |
Liquid |
| Electrical System |
24 Volt DC |
| Oil Filter |
Full flow |
| Auto Self Level |
No |
| Ground Pressure Minimum |
15.5 psi
(106.9 kPa) |
| Ground Pressure Maximum |
21.1 psi
(145.5 kPa) |
| Tilt Track Available |
No |
| Track Drive Type |
Dual path hydrostatic with planetary transmission |
| Track Length |
181.5 "
(461 cm) |
| Track Pad Type |
Double grouser |
| Track Pad Width Ranges |
30" (76.2 cm) |
| Track Size |
Cat 375 Excavator |
| Maximum Ground Speed - Low |
48.1 ft/min
(14.7 m/min) |
| Maximum Ground Speed - High |
128.4 ft/min
(39.1 m/min) |
| Parking and Emergency Brake |
spring-applied, hydraulic release, wet disc brake |
| Service Brakes |
Hydrostatic |
| Belt Width |
36 "
(91.4 cm) |
| Conveyor Belt Speed Range |
0-814 fpm |
| Conveyor Belt Style |
Finger type |
| Conveyor Length |
180" or 240" (457.2 cm or 609.6 cm) |
| Conveyor Shift Available |
Standard |
| Conveyor Shift Distance Range |
60" and 125" (152.4 cm and 317.5 cm ) |
| Conveyor Style |
Curved |
| Discharge Direction |
Right or left |
| Discharge Height Range |
74" - 103" (188 cm - 261.6 cm) |
| Trencher |
Yes |
| Terrain Leveler |
Yes |
| Rockwheel |
No |
| Bucket Wheel |
No |
| Cab |
Yes |
| Control System |
TEC Plus with SmartTEC |
| Air Conditioner/Heater |
Yes |
| Air Suspension Seat |
Yes |
| AM/FM Stereo with Weather Band |
Yes |
| Elevating |
Yes |
| Pressurized/Filtered Air |
Yes |
| Roll Over Module (ROM) |
Yes |
| Oil Tank Capacity |
210 gal
(794.9 L) |
| Oil Type |
HyPower 68, HyPower 100, Hy Power 1100 |
| Pressure Setting |
2500 psi
(172.4 bar) |
| Pump Flow at Maximum RPM |
28.7 gpm
(108.6 L/min) |
| Pump Type |
pressure-and-flow-compensated (load-sensing) |
