| Weight (basic tractor, rubber tires) |
4507 lbs
(2044.3 kg) |
| Weight (basic tractor, tracks) |
6205 lbs
(2814.5 kg) |
| Length (basic tractor, rubber tires) |
109 "
(276.9 cm) |
| Length (basic tractor, tracks) |
114 "
(289.6 cm) |
| Width (basic tractor, rubber tires) |
60 "
(152.4 cm) |
| Width (basic tractor, tracks) |
64 "
(162.6 cm) |
| Height (basic tractor, rubber tires) |
88.7 "
(225.3 cm) |
| Height (basic tractor, rubber tires, option two) |
90.3 "
(229.4 cm) |
| Height (basic tractor, tracks) |
92.6 "
(235.2 cm) |
| Wheel Base (Centerline of Axles) |
48 "
(121.9 cm) |
| Tread Width with Rubber Tires (Centerline to Centerline) |
48.8 "
(124 cm) |
| Tread Width with Rubber Tires Option Two (Centerline to Centerline) |
50 "
(127 cm) |
| Ground Clearance (rubber tires) |
7.4 "
(18.8 cm) |
| Ground Clearance (rubber tires, option two) |
9 "
(22.9 cm) |
| Ground Clearance (tracks) |
9.9 "
(25 cm) |
| Make and Model |
Deutz 2.9L D Tier4F |
| Gross Horsepower (Maximum) |
49 hp
(36.5 kw) |
| Maximum Torque |
108 ft-lb
(146.4 Nm) |
| Cooling Medium |
Oil/Coolant fluid |
| Fuel Type |
Ultra-low sulfur diesel |
| Emissions rating |
Tier 4 Final/Tier 4i (EU Stage IIIB) |
| Ground drive pump capacity |
30.1 gpm
(113.9 L/min) |
| Ground drive pump relief |
5080 psi
(350.3 bar) |
| Attachment pump capacity |
30.1 gpm
(113.9 L/min) |
| Attachment pump relief |
3450 psi
(237.9 bar) |
| Auxiliary pump capacity |
11.7 gpm
(44.3 L/min) |
| Auxiliary pump relief |
2500 psi
(172.4 bar) |
| Fuel Tank |
17.6 gal
(66.6 L) |
| Hydraulic Tank |
13 gal
(49.2 L) |
| Hydraulic System |
14.8 gal
(56 L) |
| Coolant |
1.7 gal
(6.4 L) |
| Maximum forward transport speed (high) |
3.5 mph
(5.6 km/h) |
| Maximum reverse transport speed (high) |
3.5 mph
(5.6 km/h) |
| Tire size |
26" (66 cm) |
| Maximum forward transport speed (high) |
3.8 mph
(6.1 km/h) |
| Maximum reverse transport speed (high) |
3.8 mph
(6.1 km/h) |
| Tire size |
29" (73.7 cm) |
| Maximum forward transport speed (high) |
2.9 mph
(4.7 km/h) |
| Maximum reverse transport speed (high) |
2.9 mph
(4.7 km/h) |
| Front Axle Type |
Steerable and oscillating 68/80 series planetary axles |
| Rear Axle Type |
Rigid and steerable 68/80 series planetary axles |
| Axle load rating (static, per axle) |
14837 lbs
(6730 kg) |
| Outside Turning Diameter (Rubber Tires, Front Steer Only) |
23.8 '
(7.3 m) |
| Outside Turning Diameter (Rubber Tires Option Two, Front Steer Only) |
30.3 '
(9.2 m) |
| Outside turning diameter (tracks, front steer only) |
28.5 ' |
| Outside Turning Diameter (Rubber Tires, Front and Rear Steer) |
12.9 '
(3.9 m) |
| Outside Turning Diameter (Rubber Tires Option Two, Front and Rear Steer) |
16.5 '
(5 m) |
| Outside turning diameter (tracks, front and rear steer) |
16.7 ' |
| Service Brake Type |
Hydraulic |
| Parking Brake Type |
Mechanical hand break |
